Kinetic Technologies Announces New 13W Powered Device and DC-DC Controller which integrates a 150V Output MOSFET for Space-saving Power over Ethernet (PoE) Solutions

Senior Director of ESIA Marketing at Kinetic, Phil Dewsbury, says, “The integration of the 150V rated output MOSFET coupled with 600kHz switching frequency results in more than a 25% reduction in solution size, providing our customers with the smallest 13W PoE solution on the market today, making it ideal for space critical applications. Special care has been taken to minimize EMI and to optimize the light load efficiency without the switching frequency straying into the audio band”.

KTA1136 is fully compliant with IEEE 803.2af, but also supports IEEE, 803.2at and IEEE 802.3bt specifications for Type 1 power applications. KTA1136 also includes PD Detection, classification and protection including under-voltage lockout (UVLO) and over-temperature protection (OVP).

Key applications for the new KTA1136 include Voice over IP (VoIP) Phones, Wireless LAN Access Point, Security Cameras, Biometric Authentication, Point-of-Sales Terminals, RFID Readers, Thin Clients and IoT Appliances.

Product features include:

• Compliant to IEEE® Std. 802.3af-2003 and supports Type 1 operation for IEEE® 802.3at-2009 and IEEE® 802.3bt-2018
• DC-DC Controller with two robust, integrated high voltage Power MOSFETs
  • 150V, 0.7Ω Flyback MOSFET
  • 100V, 0.49Ω Low RDS_ON Hot-Swap MOSFET
• Supports both isolated and non-isolated applications
• Adjustable switching frequency from 100kHz to 800kHz
• Programmable cycle-by-cycle DC-DC current limiting
• Input ESD surge protection to IEC61000-4-2 (Level 4)
  • Contact: ±8kV
  • Air: ±15kV
  • Other pins HBM: ±2kV
• Exceptional EMI performance
• Integrated Short-Circuit and Over-temperature Protection
• RoHS and Pb-free: TQFN-16, 4x4mm Package

Pricing and Availability

KTA1136 is available and shipping now. Pricing and more availability info please visit email: sales.europe@macnica.com.
