SL Assembly Software

Laser projection with SL Laser means saving time, reducing material use, and ensuring maximum accuracy. The SL Assembly Software plays a key role in replacing time-consuming tasks with digital precision for creating physical templates or manually aligning workpieces. This allows streamlined workflows, fewer errors, and significantly reduced production costs, whether in medium-sized workshops or large international enterprises.

Modular Design – Flexible Use

The SL Assembly Software consists of three modules, which can be used as needed:

• Module 1, included with the purchase of a SL Laser ProDirector, is used to optimize projection data. Calibration files can be generated, laser parameters defined, and additional information such as work instructions or plybooks added directly in PDF, image, or text format. This turns technical data into usable guidance for day-to-day operations.
• Module 2 is aimed at companies that want to generate their own projection data from CAD files, such as STEP, IGES, or DXF formats. An integrated drawing mode allows users to extract only the relevant contours for production and edit them as needed. Custom projection sequences can be created and modified. This is ideal for production environments with a high degree of variation.
• Module 3 is specifically designed for handling complex parts with multiple components. The software automatically detects individual elements as clips or brackets and allows users to select the lines they want to project. This enables precise alignment, positioning, and even final quality control through laser-guided projection.

Added Value Through Integration – Proven Worldwide

The SL Assembly Software clearly demonstrates how SL Laser responds to individual customer needs with functional, real-world solutions. Developed in close collaboration with production professionals, it helps establish laser projection as a complete process solution. It shows its strength from data import to visual guidance and documented execution.

The software is used worldwide by companies that demand the highest levels of precision and flexibility – from aircraft manufacturing and the space industry to serial production in mechanical engineering. Combined with SL Laser’s versatile laser projectors, it forms a complete package that pays off quickly and gives users a lasting competitive edge.

With the SL Assembly Software, SL Laser proves: those who view laser projection not just as a tool, but as part of an intelligent, integrated workflow are investing in efficiency, quality and future viability.
