NETZSCH developed a multi-screw pump for hygienic applications: The elegant solution for pumping demanding and sensitive media

NETZSCH Pumps & Systems developed a multi-screw pump for hygienic applications and expanded its previous hygienic pump portfolio with the new model series: NOTOS® 2NSH. The two-spindle positive displacement pumps are all-metal pumps that pump especially demanding and sensitive media. These pumps‘ unique feature is that they can pump large volumes while managing pressures up to 16 bar on a small footprint.

Many products in the food processing, beverage, chemicals, pharma and cosmetics industries require hygienic and safe pumping. This includes baby food, ketchup, syrups and shampoo, but also pharmaceutical ingredients. To offer even better, more customised solutions for these particularly complex tasks, the global pump expert NETZSCH, headquartered in Germany, is adding a new model to its current portfolio of hygiene pumps.

"During operation of the pump, the two intermeshing, counter-rotating screws form chambers combined with the pump housing. In these chambers, the medium is moved from the pump intake to the delivery side in a continuous axial motion,” explains Rainer Gozzer, Manager of the Global Business Field Food and Pharmaceutical at NETZSCH in Waldkraiburg. The pump achieves flow rates of up to 200 m³/h and a delivery pressure up to 16 bar. As the 2NSH is a full-metal pump where the lobe rotors do not touch, the pump does not pose any potential for contamination. Dry running is also not a risk with the new unit. The pump can be cleaned (CIP) and sterilised (SIP) efficiently. During the CIP cleaning process, the 2NSH is used as a conveying pump and as a pressure-increasing pump during cleaning.

Also, the pump offers various advantages, depending on the version: In the FSIP® version, it does not have to be removed from the pipeline for maintenance. It is therefore particularly user-friendly. The conventional version, on the other hand, can be equipped with a heating jacket. In this way, it conveys a heat-dependent medium at a constant temperature and ensures flowability. The conventional 2NSH can also be used for container emptying and impresses with a residual value in the container of less than 1 %. Depending on the application, NETZSCH offers the best pump for every operator.

Über die NETZSCH Pumpen & Systeme GmbH

For over 60 years, NETZSCH Pumps & Systems has served markets worldwide with NEMO® progressing cavity pumps, TORNADO® rotary lobe pumps, NOTOS® multi screw pumps, grinding machines, barrel emptying systems, dosing technology and accessories, providing customised, sophisticated solutions for applications in every type of industry. With a workforce of over 2,000 and a turnover of more than 275 million Euro (the financial year 2019), NETZSCH Pumps & Systems is the largest business unit with the highest turnover in the NETZSCH Group, alongside NETZSCH Analysing & Testing and NETZSCH Grinding & Dispersing. Our standards are high. We promise our customers "Proven Excellence" – outstanding products and services in all areas. We have shown that we can keep this promise time and again since 1873.
