How to enhance your EtherCAT master with best real-time DAQ

Therefore you are now able to integrate our high-performance Q.series X I/O modules into all industry standard EtherCAT masters like TwinCat, Koenig KPA, NI VeriStand, and Acontis.

EtherCAT was developed with industrial automation in mind, so finding EtherCAT-ready high-accuracy data acquisition devices which cover a wide range of sensors can be a challenge. Modern data acquisition system vendors such as Gantner Instruments offer a full range of measurement modules with a direct EtherCAT interface. There is no limitation in the type of sensors you can use within an EtherCAT-based data acquisition system: thermocouple, Pt100, LVDT, strain gage, IEPE/ICP©, piezoelectric (charge), high-voltage measurement up to 1200 VDC, and even fiber Bragg grating sensors.

Gantner Instruments provides you with robust I/O modules with the best-in-class accuracy, high stability, and minimal noise without long-term drift for all of the measurement types mentioned above. What do we mean by best-in-class accuracy?

Here are three examples:

  • The margin of error for our A105 I/O module with four channels for RTD measurements is 0.05 K at a resolution of 100 µK.
  • Our A108 I/O module brings eight channels of voltage or current measurements with an error margin of +/-2 mV for an input range of +/-10 V with a resolution of 1.5 µV.
  • Our A116 I/O module can support eight inputs of quarter-, half-, and full-bridge strain-gages with an accuracy as low as 0.05 %.

Check out our datasheets to see the facts of our other I/O modules.

The Q.series X line of I/O modules is equpipped with pre-engineered signal conditioning functionality out-of-the-box. There is no need to program filters, linearization curves, or sensor scaling functions. With Gantner’s configuration software GI.bench, all configuration is done by mouse click, and also arithmetic functions like RMS, min., max., and average are set without any programming necessary. Suppose you choose a module that includes digital outputs. In that case, you can trigger an alarm output independent from any interaction with the master stack by defining a threshold directly on the I/O module.

We are delighted to tell you that the Q.series X offers much more features.

With the Q.station X EC which is our test controller with an EtherCAT slave interface, you can benefit from its advanced data acquisition functionality in parallel with communicating on an EtherCAT network. You can configure up to 20 continuous data loggers along with independent event triggered loggers for data storage at sample rates significantly higher than most EtherCAT industrial master stack could ever do. Furthermore, arithmetic functions are available for live signal processing, e.g., spectral band analysis with built-in FFT processing or mathematical functions for feature extraction. The resulting arithmetic variables can be transferred to the EtherCAT master in addition to the measurement values.

Benefits in using our DAQ Platform

  • Pre-engineered data acquisition functionality
  • Out-of-the-box signal conditioning
  • 20 continuous and triggered data loggers
  • Significantly higher data rates
  • Arithmetic, linearization and scaling functions
  • No Sensor limitation
  • Filtering onboard
  • Alarm triggering
  • 3-way 500 VDC galvanic isolation

Our Q.series X are in stock and we are able to deliver very fast.
Don’t miss this chance and request a quote now!

Why Gantner Instruments DAQ modules make your life easier?

All Gantner Instruments I/O modules are fully compliant with the EtherCAT slave specifications from the EtherCAT Technology Group (ETG). Our I/O modules can connect with any EtherCAT master stack that follows these ETG specifications. To make integration with your master stack as simple as ABC, we provide various options for setting up our I/O modules in your EtherCAT master:

  • EtherCAT Slave Information (ESI) file:
    With our GI.bench DAQ software, you can configure the I/O modules then easily export ESI files, which is the XML file used by many EtherCAT masters to configure slave devices and generate network description files.
  • CoE online scan:
    The dynamic exchange of configuration settings between slave modules and the EtherCAT master using CAN Application Protocol over EtherCAT (CoE). This feature is supported by more advanced EtherCAT masters and offers extended flexibility between various hardware platforms all using EtherCAT.
  • Direct EtherCAT master interface:
    Our GI.bench software offers the unique capability to interface with several EtherCAT master stacks to configure I/O modules directly via File Access over EtherCAT (FoE). This outstanding functionality is available for TwinCAT, the EC Master stack from Acontis, and the KPA master from koenig-pa GmbH.
