Fanless embedded system with Hailo-8 support

ICP Germany offers with the new E310-10EHI an embedded system, which is prepared for the use as an inference system. The E310-10EHI offers the possibility to be extended by a Hailo-8TM KI IC. The Hailo-8TM extension enables the E310 to perform inference directly at the edge. Data can thus be processed and analyzed directly at the machine and decisions can be made in "real time" without relying on the cloud. The E310-10EHI is equipped with an Intel® Elkhart Lake Celeron J6413 processor. The processor unit has four processor cores and four threads and operates at a base clock speed of 1.8GHz which can be ramped up to 3.0GHz if required. Other processors from the 11th Elkahrt Lake generation are optionally available. Up to 32GB of RAM can be installed in the two DDR4 SO-DIMM slots. For connecting monitors, the system offers an HDMI and a Display Port connection with a resolution of up to 4K. Storage media can be installed in the E310-10EHI’s 2.5" slot, in the M.2 2280/2262/2242 SSD slot, as well as in the mSATA slot. Furthermore, the E310-10EHI offers two GbE ports with Intel® I211-AT network IC, four USB 2.0, two USB 3.2, and two COM interfaces. The E310-10EHI-J6413 can be operated fanless in a temperature range of -20 °C to 60 °C with an input voltage of 8~24V. On request, ICP Germany supplies the E310-10EHI-J6413 as a ready-to-use system with suitable industrial memory modules and solid state disks.

Specifications

• Intel® Elkhart Lake Celeron® J6413 CPU
• 2 x DDR4 SO-DIMM for up to 32GB memory
• 2 3042/3052 + SIM slot for 5G
• HDMI, DisplayPort, Dual GbE
• 0, USB3.1, RS-232
• Edge KI Hailo-8 support
• 8~24V DC input

Applications

• Automatisierung
• Industrielle Steuerung
• Machine Vision
• Datenlogger
• Industrie PC
