• Optische Technologien

    Polarization-controlled VCSEL testing

    At LASER WoP 2022 Instrument Systems will be presenting its latest VTC 4000 infrared camera for the near-field analysis of narrow-band emitters, e.g. VCSELs or lasers. Industry-standard VCSELs emit in more than one polarization state, each with different polarization angles, thus impeding error-free measurement. Thanks to a new one-shot process, the VTC 4000 simultaneously measures the spatial polarization of single emitters of an array and supplies the necessary information to reduce the polarization dependency of the measurement setup. This procedure minimizes the error budget of the VCSEL test system and provides highly accurate measured values for the eye safety of the laser source. This enables manufacturers to exploit the full…

  • Optische Technologien

    Polarisationskontrolliertes VCSEL-Testing

    Instrument Systems präsentiert auf der LASER WoP 2022 seine neueste Infrarot-Kamera VTC 4000 zur Nahfeldanalyse von schmalbandigen Emittern wie z.B. VCSEL oder Lasern. Industrieübliche VCSEL emittieren in mehr als einem Polarisationszustand mit jeweils unterschiedlichen Polarisationswinkeln und erschweren so ihre fehlerfreie Vermessung. Dank neuartigem One-Shot-Verfahren misst die VTC 4000 simultan die räumliche Polarisation einzelner Emitter eines Arrays und liefert notwendige Informationen, um die Polarisationsabhängigkeit des Messaufbaus zu reduzieren. Dieses Vorgehen minimiert das Fehlerbudget des VCSEL-Testsystems und liefert hochgenaue Messwerte für die Augensicherheit der Laserquelle. Hersteller können hierdurch die volle Leistungseffizienz von VCSEL/Lasern ausschöpfen und gleichzeitig einen sicheren Betrieb gewährleisten. Besuchen Sie uns am Stand A6.221.   VCSEL sind Bauelemente mit intrinsischem…

  • Optische Technologien

    High-performance for wavelengths in infrared

    At LASER WoP 2022 Instrument Systems will be presenting its latest spectroradiometer CAS 140D IR for measurements in the SWIR (short-wave infrared) wavelength range. The latter offers the proven high measurement accuracy and reliability of the CAS140D series – internationally recognized as a reference – for wavelengths of 780–1700 nm. Compared to its predecessor, the CAS 140D IR has a significantly better performance in signal sensitivity, stray light suppression and electronics. Visit us at booth A6.221.   For over 35 years Instrument Systems has been a hallmark of excellence in light measurement technology. This is especially true for the globally recognized high-end spectroradiometers. They are the key component for a…

  • Optische Technologien

    High-Performance für Wellenlängen im Infrarot

    Instrument Systems präsentiert auf der LASER WoP 2022 sein neuestes Spektralradiometer CAS 140D IR für Messungen im SWIR (short-wave infrared) Wellenlängenbereich. Es bietet die bewährte hohe Messgenauigkeit und Zuverlässigkeit der weltweit als Referenz anerkannten CAS140D-Serie für Wellenlängen von 780 – 1700 nm. Gegenüber seinem Vorgängermodell besitzt das CAS 140D IR eine deutlich verbesserte Performance bei der Signalsensitivität, der Streulichtunterdrückung und der Elektronik. Besuchen Sie uns an Stand A6.221.   Seit über 35 Jahren steht Instrument Systems für höchste Ansprüche in der Lichtmesstechnik. Dies gilt insbesondere für die weltweit anerkannten High-end Spektralradiometer. Sie sind das Kernstück für unterschiedlichste Lichtmessaufgaben in vielfältigen, innovativen Applikationen. Alle radiometrischen, photometrischen und farbmetrischen Eigenschaften werden mithilfe…

  • Produktionstechnik

    LIV-Testsysteme für Laserdioden

    Instrument Systems präsentiert auf der LASER WoP 2022 sein umfangreiches Testportfolio für IR-Emitter und VCSEL. Neue Produktentwicklungen im Bereich der Spektralradiometer der CAS-Serie und der VTC Near-/Far-Field-Kameras bedienen den immens gewachsenen Markt der Laserdioden-Produktion für den kurzwelligen Infrarot-Bereich von 900 bis 1700 nm. Mit dem passenden LIV-Test-Equipment – zusätzlich bestehend aus Ulbricht-Kugeln, Photodioden, Source-Measure-Units (SMUs) und Temperaturreglern – können Laserdioden vollumfänglich optisch charakterisiert werden. Die Software-Applikation SpecWin Pro unterstützt bei der Charakterisierung von Laserdioden durch die Integration und präzise Synchronisierung aller Messgeräte sowie die numerische und grafische Analyse der Daten. Besuchen Sie uns an Stand A6.221.   Der LIV-Test ist eine schnelle und einfache Methode, um die wesentlichen Performance-Parameter von…

  • Produktionstechnik

    LIV test systems for laser diodes

    Instrument Systems develops flexible light measurement solutions for the optical characterization and inspection of laser diodes in the lab and production. At LASER WoP 2022 Instrument Systems will be showcasing its extensive test portfolio of IR emitters and VCSELs. New product developments in the fields of spectroradiometers of the CAS series and the VTC near-/far-field cameras serve the fast-growing market for laser diode production in the short-wave infrared range of 900 to 1700 nm. Laser diodes can be optically characterized in detail with the appropriate LIV test equipment – additionally consisting of integrating spheres, photodiodes, source-measure-units (SMUs) and temperature controllers. The software application SpecWin Pro supports the characterization of laser…

  • Produktionstechnik

    Laser safety for 3D sensor applications

    Characterization of VCSEL elements for 3D sensor applications to IEC60825-1: Instrument Systems has developed a practical method of laser safety assessment for the pulsed VCSEL arrays frequently used in consumer electronics and LiDAR applications. Instrument Systems has developed a practicable concept for the laser safety assessment of VCSELs based on the international laser safety standard. With absolutely calibrated and modular test systems, such as the pulsed VCSEL tester PVT 100/110 and camera-based VTC 2400, the complete characterization of pulsed VCSEL arrays is possible. Since VCSEL arrays are experiencing a drastic growth in 3D sensor applications, e.g. face ID, automotive LiDAR and human-machine-interfaces (AR/VR), proof of eye safety is becoming increasingly…

  • Produktionstechnik

    Lasersicherheit für 3D-Sensoranwendungen

    Charakterisierung von VCSEL-Elementen für 3D-Sensoranwendungen gemäß IEC60825-1: Instrument Systems lanciert eine praxisnahe Lasersicherheitsbewertung für gepulste VCSEL-Arrays, die häufig in Consumer Electronics und in LiDAR-Anwendungen eingesetzt werden. Instrument Systems hat, basierend auf der internationalen Lasersicherheitsnorm, ein praxistaugliches Konzept zur Lasersicherheitsbewertung von VCSEL entwickelt. Mit absolut kalibrierten und modularen Testsystemen, wie dem Pulsed VCSEL Tester PVT 100/110 und der kamerabasierten VTC 2400, kann eine vollständige Charakterisierung gepulster VCSEL-Arrays durchgeführt werden. Da VCSEL-Arrays ein drastisches Wachstum bei 3D-Sensoranwendungen – wie z.B. Face ID, Automotive LiDAR und Human-Machine-Interfaces (AR/VR) – verzeichnen, wird der Nachweis ihrer Augensicherheit immer wichtiger. Oberflächenemittierende Laser (VCSEL) sind seit mehr als drei Jahrzehnten in industriellen Anwendungen im Einsatz. Seit einigen…

  • Produktionstechnik

    UVC calibration standards with accredited test procedure

    Instrument Systems has been accredited for tests in the field of lighting technology to DIN EN ISO / IEC 17025 since 2009 and is now offering accredited testing of radiant flux and luminous flux with the “Goniospectroradiometry of optical radiation sources” procedure. This procedure has enabled the development of UVC-LED reference sources with traceable reference values of maximum precision for radiant flux and irradiance. These reference sources are used for monitoring and calibrating UV measuring equipment, e.g. the ISP-PTFE series. The accreditation of test labs is extremely important for photometry customers. With it they receive the assurance that their measuring equipment delivers reliable and traceable results. At the same time,…

  • Produktionstechnik

    Mit akkreditierten Prüfverfahren zu UVC-Kalibrierstandards

    Instrument Systems ist seit 2009 für Prüfungen im Bereich Lichttechnik nach DIN EN ISO / IEC 17025 akkreditiert und bietet seit neuestem auch die akkreditierte Prüfung von Strahlungsleistung und Lichtstrom mit dem Verfahren der „Goniospektroradiometrie von optischen Strahlungsquellen“ an. Das Verfahren ermöglichte die Entwicklung von UVC-LED-Referenzquellen mit rückführbaren Referenzwerten höchster Genauigkeit für Strahlungsleistung und Bestrahlungsstärke. Diese Referenzquellen werden für das Monitoring sowie die Kalibrierung von UV-Messequipment, wie z.B. der ISP-PTFE-Serie, verwendet. Die Akkreditierung von Prüflaboren ist für Kunden der Lichtmesstechnik enorm wichtig. Sie erhalten mit ihr die Gewissheit, dass ihre Messgeräte zuverlässige und rückführbare Ergebnisse liefern. Die akkreditierte Prüfung der oftmals in der Produktion eingesetzten Messgeräte stellt gleichzeitig eine hohe…
