• Elektrotechnik

    ODU MEDI-SNAP® : Controlliamo l’alta tensione

    I test nei settori delle batterie per la mobilità elettrica, dell’energia solare e dell’alta tensione devono essere eseguiti rispettando adeguati requisiti di sicurezza per proteggere l’utente. Sul mercato esistono molti connettori specificati per essere usati con tensioni fino a 1 kV AC/DC. Tuttavia, la selezione diventa significativamente più piccola se si desidera effettuare misure tra 1 kV e 1,6 kV CA/DC. Una sfida è quella di soddisfare la norma DIN EN IEC 61010-2-030:2022-11 / VDE 0411-2-030:2022-11 anche nel più piccolo spazio di installazione di un connettore. In particolare, è estremamente importante mantenere le distanze di scarica superficiale necessarie (rispettivamente almeno 22 mm e 32 mm) tra le parti sotto tensione…

    Kommentare deaktiviert für ODU MEDI-SNAP® : Controlliamo l’alta tensione
  • Elektrotechnik

    ODU MEDI-SNAP®. Nous contrôlons la haute tension

    Les tests dans les domaines des batteries pour les véhicules électriques, du solaire et de la haute tension doivent être réalisés dans le respect des exigences de sécurité afin de protéger l’utilisateur. Il existe de nombreux connecteurs sur le marché qui sont spécifiés pour une utilisation jusqu’à 1 kV AC/DC. Le choix se réduit toutefois considérablement si l’on souhaite effectuer des mesures entre 1 kV et 1,6 kV AC/DC. L’un des défis est ici de satisfaire à la norme DIN EN IEC 61010-2-030:2022-11 / VDE 0411-2-030:2022-11, avec un connecteur à encombrement réduit. Il est particulièrement important de respecter les lignes de fuite et les distances d’isolement dans l’air nécessaires (respectivement…

    Kommentare deaktiviert für ODU MEDI-SNAP®. Nous contrôlons la haute tension
  • Elektrotechnik

    ODU MEDI-SNAP®: We control high-voltage

    Measurement and testing in the areas of e-mobility batteries, solar and high-voltage in general must be carried out while fulfilling the appropriate safety requirements in order to protect the user. There are many connectors on the market that are specified for measuring up to 1 kV AC/DC. However, the selection of possible connector solutions becomes significantly reduced if you want to carry out measurements between 1 kV and 1.6 kV AC/DC. One challenge here is to fulfil DIN EN IEC 61010-2-030:2022-11 / VDE 0411-2-030:2022-11. This becomes even more difficult if you have further restrictions on the available installation space for the connector. In particular, compliance with the necessary creepage and…

    Kommentare deaktiviert für ODU MEDI-SNAP®: We control high-voltage
  • Elektrotechnik

    ODU-MAC® Blue-Line Push-Lock: Neue Kabel-zu-Kabel-Lösung

    In Bereichen wie der Mess- und Prüftechnik, Industrie- oder Robotik-Anwendungen ist mitunter Flexibilität gefordert. Neben den Vorteilen der modularen Steckverbinder, die bereits einen hohen Grad an Variabilität ermöglichen, gibt es Anwendungen mit der Anforderung, zwei Kabel steckbar miteinander zu gestalten. Diese Schnittstelle bietet ODU mit dem neuen ODU-MAC® Blue-Line Push-Lock In-Line Receptacle. Haptisches und akustisches Feedback Der Push-Lock bietet mit dem In-Line Receptacle die bereits bekannten Vorteile. So verfügt er über dieselbe Push-Pull-Verriegelung, die nicht nur ein optimales Handling ermöglicht, sondern auch mit haptischem und akustischem Feedback eine erfolgreiche Verbindung meldet. Mit 6 optionalen Kodierungsmöglichkeiten wird zudem ein unbeabsichtigtes Fehlstecken verhindert. Die Gesamtlösung mit Schutzart IP66 bietet über 5.000 Steckzyklen…

    Kommentare deaktiviert für ODU-MAC® Blue-Line Push-Lock: Neue Kabel-zu-Kabel-Lösung
  • Elektrotechnik

    ODU-MAC® Blue-Line Push-Lock: nuova soluzione cavo-cavo

    La flessibilità è talvolta richiesta nei sistemi di test & measurement, nelle applicazioni industriali o in robotica. Oltre ai vantaggi dei connettori modulari, che già consentono un elevato grado di configurabilità, esistono applicazioni che richiedono che due cavi “volanti” vengano collegati tra loro. ODU offre questa possibilità con la nuova presa in linea ODU-MAC® Blue-Line Push-Lock. Feedback aptico e acustico Anche nella sua versione per connessioni volanti, il connettore Push-Lock offre i noti vantaggi: è dotato dello stesso meccanismo di chiusura push-pull, che non solo consente una connessione agevole, ma fornisce anche un feedback aptico e acustico per indicare il buon esito della connessione. Con 6 opzioni di codifica opzionali,…

    Kommentare deaktiviert für ODU-MAC® Blue-Line Push-Lock: nuova soluzione cavo-cavo
  • Elektrotechnik

    ODU-MAC® Blue-Line Push-Lock: NEW CABLE-TO-CABLE SOLUTION

    Flexibility is often required when finding a solution for tasks in test and measurement, industrial or robotics applications. In addition to the advantages of modular connectors, ODU now offers a clever solution for pluggable cable connections with the new ODU-MAC® Blue-Line Push-Lock In-Line Receptacle. Haptic and acoustic feedback With the in-line receptacle, the Push-Lock offers the already familiar advantages. It has the same push-pull locking mechanism, which not only enables optimum handling, but also provides haptic and acoustic feedback to indicate a successful connection. With 6 coding options, unintentional mismating is also prevented. The complete solution with IP66 protection offers over 5,000 mating cycles and the tool-free clip assembly typical…

    Kommentare deaktiviert für ODU-MAC® Blue-Line Push-Lock: NEW CABLE-TO-CABLE SOLUTION
  • Elektrotechnik

    ODU präsentiert Mass Interconnect, Power und High-Voltage Lösungen

    Wo Automotive auf Testing trifft, sind die Anforderungen an Steckverbindungen hoch: Viele Steckzyklen, höchste Präzision und Zuverlässigkeit sind die Kriterien, in denen Sie überzeugen müssen. Ob im Bereich Mass Interconnect, dessen schiere Anzahl an Signalen eine Herausforderung darstellt, im Bereich Power, in dem höchste Ströme übertragen werden müssen, oder im Bereich High-Voltage mit hoher Spannung und kleinem Bauraum. Alle Bereiche sind auf funktionierende und ebenso exakte wie belastbare Messungen angewiesen. ODU präsentiert 2025 eine Fülle an Erweiterungen des Produktsortiments. Mit Spannung erwartet: ODU MEDI-SNAP® 1,6 kV High-Voltage trifft auf kleinen Bauraum: Mit dem MEDI-SNAP® hat ODU ein Produkt im Portfolio, das sich besonders für den Bereich High-Voltage eignet und zahllose…

    Kommentare deaktiviert für ODU präsentiert Mass Interconnect, Power und High-Voltage Lösungen
  • Elektrotechnik

    ODU presents new Push-Lock Medical

    ODU, a leading supplier of high-quality connector solutions, is expanding its portfolio with the new Push-Lock Medical – a variant of the proven modular ODU-MAC® Blue-Line connector tailored to the medical environment. This innovative solution combines a compact design, easy handling and maximum flexibility and is aimed at applications that place the highest demands on hygiene, reliability and user-friendliness. The Push-Lock Medical features an intuitive push-pull locking mechanism that ensures a fast, secure and error-free connection. This connector offers clear added value, particularly in medical technology, where efficiency and precision are crucial in day-to-day work. The modularity of the system allows individual adaptation to the specific requirements of the application,…

    Kommentare deaktiviert für ODU presents new Push-Lock Medical
  • Medizintechnik

    ODU presenta il nuovo Push-Lock Medical

    ODU, fornitore leader di soluzioni di connessione di alta qualità, amplia il suo portafoglio con il nuovo Push-Lock Medical, una versione del suo collaudato connettore modulare Blue-Line adattata all’ambiente medico. Questa soluzione innovativa combina un design compatto, facilità d’uso e massima flessibilità ed è destinata ad applicazioni che pongono i massimi requisiti di igiene, affidabilità e facilità d’uso. Il Push-Lock Medical si distingue per il suo intuitivo meccanismo di chiusura push-pull, che garantisce una connessione rapida, sicura e senza errori. Questo connettore offre un chiaro valore aggiunto in particolare nel settore della tecnologia medica, dove l’efficienza e la precisione sono fondamentali nel lavoro quotidiano. La modularità del sistema permette di…

    Kommentare deaktiviert für ODU presenta il nuovo Push-Lock Medical
  • Elektrotechnik

    ODU stellt neuen Push-Lock Medical vor

    ODU, führender Anbieter für hochwertige Steckverbindungslösungen, erweitert sein Portfolio um den neuen Push-Lock Medical – eine auf das medizinische Umfeld zugeschnittene Variante seines bewährten modularen ODU-MAC® Blue-Line Steckverbinders. Diese innovative Lösung kombiniert ein kompaktes Design, einfache Handhabung und maximale Flexibilität und richtet sich an Anwendungen, die höchste Ansprüche an Hygiene, Zuverlässigkeit und Benutzerfreundlichkeit stellen. Der Push-Lock Medical überzeugt durch einen intuitiven Push-Pull-Verriegelungsmechanismus, der eine schnelle, sichere und fehlerfreie Verbindung gewährleistet. Besonders in der Medizintechnik, wo Effizienz und Präzision im Arbeitsalltag entscheidend sind, bietet dieser Steckverbinder einen klaren Mehrwert. Die Modularität des Systems ermöglicht eine individuelle Anpassung an die spezifischen Anforderungen der jeweiligen Anwendung, von der Signal- und Datenübertragung bis hin…

    Kommentare deaktiviert für ODU stellt neuen Push-Lock Medical vor
