Ultra-wideband antennas for radial isotropic measurements from 150 MHz to 18 GHz

15th Septmber The successful Aaronia broadband antenna series OmniLOG is extended by the OmniLOG PRO Antennas. Aaronia, the specialist for low and high frequency measurement technology, offers the new series in eight versions. What they all have in common is that they consist of a frequency-optimised ultra-wideband antenna that can also be used as a transmitting antenna (1W or 100W). Due to their extremely high bandwidth of up to 18GHz, only one antenna is required for complete frequency monitoring. Broadband monitoring solutions (conference room monitoring, direction finding, spectrum monitoring, multi-band monitoring, etc.) become child’s play. Antenna switching with the associated antenna forest is a thing of the past. Due to its optional transmission power of up to 100W, broadband transmission applications up to reactive jamming are also possible.

The small and lightweight antennas of the OmniLOG PRO series are all suitable for outdoor use. An IP65 certified antenna chassis provides secure protection against environmental influences. The magnetic antenna base allows temporary fixed installation, for example on the roof of a car during measurement runs.

The complete calibration data (50 MHz steps) for all antennas can be downloaded from the Aaronia website. This also makes the antenna suitable for EMC measurements.

Before an antenna leaves Aaronia AG, it is tested extensively and subjected to strict quality control. This high-quality standard applies to all Aaronia antennas without exception. All broadband antennas are developed, individually manufactured and calibrated by Aaronia in Germany. This guarantees the highest quality standards, allowing Aaronia to offer every customer a full 2-year warranty on all EMC antennas.

Features

  • Optimal for omnidirectional measurements
  • Very cost effective
  • Small and lightweight
  • For laboratory and outdoor measurements
  • Covers all mobile radio frequencies
  • Magnetic base included
  • Includes typical calibration data

Use

  • LTE800
  • ISM868
  • GSM900
  • GSM1800
  • GSM1900
  • DECT
  • UMTS
  • WLAN
  • Microwave
  • Bluetooth
Über die Aaronia AG

Aaronia AG is a technology company located in Strickscheid in the Eifel / Germany.
The company was founded in 2003 by Thorsten Chmielus and mainly produces spectrum analysers based on patented spectrum analysis processes. In 2004 the first Spectrum Analyser was produced and delivered. In 2008, the next generation of spectrum analysers was presented with the V4 series, which set a world record in handheld sensitivity of DANL -170dBM (Hz). In 2016, Aaronia launched the Spectran V5 series, the world’s first and only handheld real-time spectrum analysers. The frequency range was extended from 9.4GHz up to 20GHz for the V5 series.
The present object of the company is the development, trade and distribution of measuring instruments, technologies and rights in the field of low and high frequency measurement technology, robotics, as well as the shielding of low and high frequency fields of any kind and basic research in the field of communications and measurement technology; furthermore, the construction of own circuitry and measurement methods especially for the development of extremely sensitive and accurate high frequency measurement technology.
